Gerab supplies pumps to various types and standards to suit the oil, power and process industries

Gerab has a tie up with DALIAN DEEP BLUE PUMP, One of the leading pumps manufacturers in China, the recognized top Chinese industrial centrifugal pumps manufacturer, especially for API610 pumps, one of three Chinese nuclear power station pumps manufacturers approved by the China National Nuclear Security Administration.

Deep Blue Pump does the whole complete production process from R&D and engineering, melting and casting, to machining and fabrication, to assembly, to testing and inspection, to supply after-market products, repair, and diagnostic services.

The EAP-I series is a horizontal, radial-split, single-stage, single-suction overhung centrifugal pump with a volute casing. It features a double volute casing structure with an outlet diameter greater than or equal to 80mm that can effectively balance the radial force and ensure the shaft deflection at the shaft seal. The pump is centerline-mounted and is suitable for high-temperature media. A balance hole and seal ring combination is used to balance the axial force over the service life of the bearing. The pump casing, cover, and impeller are provided with sealing rings, and the interference fit of the sealing rings is fixed with screws. This pump is suitable for working conditions with granular impurities without compromising the service life of the pump casing, cover, or impeller.

  • Capacity 2~2600m3/h
  • Head ~300m
  • Design Pressure 5.0Mpa
  • Temperature -80~+450℃
  • Speed 2980r/min 1475r/min
  • Power ~1120KW

The EAP-K series is a horizontal, radial-split, single-stage, overhung centrifugal pump with a volute casing. The pump is centerline-mounted, featuring a double casing structure with an outlet diameter greater than or equal to 80mm and an open impeller. The pump casing and cover are equipped with front and rear wear-resistant plates. The bearing component is designed with a bearing box structure to adjust the axial momentum of the rotor. The pump has a rigid shaft design that ensures smooth running of the rotor. A back blade balances the axial force, ensuring the service life of the bearing. The radial bearings are cylindrical roller bearings and the thrust bearings are angular contact ball bearings, which can properly bear axial forces from two directions.

  • Capacity 2~2600m3/h
  • Head ~280m
  • Design Pressure ~5.0MPa
  • Temperature -80~+450℃
  • Speed 2980r/min 1475r/min
  • Power ~1120KW

The EAP-G series is a horizontal, radial-split, single-stage, single-suction overhung centrifugal pump with a volute casing. It features a double casing structure with an outlet diameter greater than or equal to 80mm that can effectively balance the radial force and ensure the shaft deflection at the shaft seal. The pump is centerline-mounted and is suitable for any temperature medium. The inlet and outlet flanges are arranged on the pump casing for easy inspection and maintenance without the need to move the suction and discharge pipelines. With a no-balanced hole structure, the shaft head force generated by high pressure at the pump inlet can be offset by the impeller cover force, and the residual axial force is borne by the tapered roller bearing. The throat bushing is designed with a labyrinth groove or effective thread groove structure that can effectively cut off high-temperature heat sources and control the pressure of the sealing chamber.

  • Capacity 2~1500m3/h
  • Head ~280m
  • Design Pressure ~10.0Mpa
  • Temperature -80~+450℃
  • Speed 2980r/min 1475r/min
  • Power ~1120KW

The ANS-B series is q horizontal, radial split, single stage, single suction, overhung centrifugal pump with a foot-mounted volute casing, The impeller is designed as a fully open structure with a back blade, which is suitable for abrasive liquids containing large particles or strip fibers. The Rigid shaft design, impeller and shaft are connected by a thread with no impeller nut. The bearing component is provided with a bearing box structure and a connecting-bolts plus jacking-bolts design for the bearing housing and bearing box so that the clearance between the impeller and the casing can be easily adjusted without disassembling the pump. This ensures that the pump can run within the high efficiency range. The adjusting action is easy and reliable and the maintenance is simple. The radial bearings are deep groove ball bearings and the thrust bearings are angular contact ball bearings, which can withstand axial forces from two directions.

  • Capacity 2~1250m3/h
  • Head ~145m
  • Design Pressure ~2.5Mpa
  • Temperature -40~+200℃
  • Speed 2980r/min 1475r/min
  • Power ~160KW

The EDS series is horizontal, axially split, double-suction, single stage or two stages, between-bearings, centerline-mounted or foot-mounted centrifugal pump. The double volute structure reduces the radial force effectively. The axial split structure helps rapid disassembly of the rotor and parts maintenance without disassembling the pipeline and the pipeline-related system Single-stage double-suction or two-stage double-suction + single-stage structure impeller, high cavitation resistance, high efficiency and stability. Self-balancing axial force, no complex balance disc, balance drum and other balance mechanisms. EDS series pump is a new generation of high-efficiency energy-saving products with a three-dimensional model and CFD flow field analysis, a wide range of flow, high efficiency and good cavitation resistance.

  • Capacity 100~12000m3/h
  • Head ~440m
  • Design Pressure Single stage:2.5~10.0Mpa
    Double stage :5.0~15.0Mpa
  • Temperature -40~+200℃
  • Speed Single stage:~2980r/min 1475r/min 980r/min 735r/min
    Double stage :~2980r/min 1475r/min
  • Power ~3150KW

The HDD series is a horizontal, radial split, double suction, centrifugal pump with volute casing that can be configured as single or two stages. It can be centerline-mounted, with top-suction, top-discharge or side-suction, side-discharge/side-suction, top-discharge options. The spiral suction chamber provides better flow conditions, and a uniform velocity field is achieved at the impeller inlet. The double-suction impeller has improved cavitation performance, reducing installation costs and prolonging bearing life. The pump features a rigid shaft design, with a first-order critical speed that is more than 1.2 times the designed speed, ensuring smooth operation.

  • Capacity 50~6300m3/h
  • Head ~700m
  • Design Pressure ~15.0MPa
  • Temperature -80~+450℃
  • Speed 2980r/min 1475r/min
  • Power ~2800KW

The SCSK Series is a horizontal, single-casing, axial-split, centerline-mounted, multistage pump with symmetrically arranged impellers. The inlet and outlet flanges are arranged on the pump casing to allow for easy detection and maintenance of the pump without having to move the suction and discharge pipelines. The impellers are arranged back-to-back in a symmetrical manner, resulting in a small residual axial force. The axial force is balanced by adjusting the size of the throttle bushing and other parts, eliminating the need for complex balancing devices. Additionally, the inner hole of each shaft sleeve is equipped with a spiral groove, and the axial dimension of the shaft sleeve is short, making it especially suitable for transferring liquids containing particles. The static friction pair is designed in a separate structure, making it more convenient and faster to replace. The rotor parts do not need to be disassembled and installed again after dynamic balance.

  • Capacity 20~1680m3/h
  • Head ~1850m
  • Design Pressure ~5MPa~15MPa
  • Temperature -80~+200℃
  • Speed 2980r/min
  • Power ~3150KW

The SCS series is a horizontal, radial-split, multistage, ring-section pump. It features a radial diffuser-type casing structure, and can be centerline or foot-mounted based on the operating temperature. The flexible arrangements of the suction and discharge ports allow for various installation options. This series is characterized by its simple and reliable structure, high stability, long service life, and easy maintenance. The series features arrangement impellers and double-balancing drums to balance the axial force. The flexible design in dry state and rigid design in wet state of the rotor ensures stable and reliable operation. The first-stage impeller and second-stage impeller are different designs, with the first-stage impeller having high anti-cavitation performance and the second-stage impeller offering high efficiency. The impellers are designed as sliding structures, making them easy to install and disassemble.

  • Capacity 3~250m3/h
  • Head ~1200m
  • Design Pressure ~11.0MPa
  • Temperature -30~+180℃
  • Speed 2980r/min
  • Power ~1500KW

The SCS-Z series is a horizontal, single-casing, radial-split, ring-section, multistage pump with symmetrically arranged impellers. It can be centerline-mounted or foot-mounted. The impellers are arranged back-to-back, and the axial force is self-balancing. The flexible design in dry state and rigid design in wet state of the rotor ensure stable and reliable operation. The first-stage impeller and second-stage impeller are different designs, with the first-stage impeller being based on high cavitation-resistance.

  • Capacity 5~900m3/h
  • Head ~1600m
  • Design Pressure ~20.0Mpa
  • Temperature -80~+210℃
  • Speed ~2980r/min
  • Power ~2500KW

SCS-G series is horizontal, single-casing, radial split,ring-section ,multistage pump with series arrangement impellers .Advanced hydraulic design methods such as CFD 3D flow field analysis ensure the pump high efficiency and good cavitation performance.Single or double balancing drum structure is applied to balance the axial force, to ensure the stable and reliable operation. The first stage impeller is the low cavitation design.Self-lubricating bearings or forced lubricating bearings could be applied for different power, speed and other service requirement

  • Capacity 5~1200m3/h
  • Head ~2000m
  • Design Pressure ~26.0Mpa
  • Temperature -40~+180℃
  • Speed 2980r/min
  • Power ~8000KW

DCS-Z series is horizontal, double-casing, radial split, symmetrical arrangement impellers, multistage pump. The pump is centerline-mounted, heavy-duty design, good thermal stability, and properly satisfies the nozzle load requirements specified by API610. Double casing structure secures high safety and reliability; The inner casing is an integrally pull-out design, of which the pump could be easily installed and maintained. The impellers are arranged back to back without the traditional balance device to ensure stable and reliable operation. The first stage impeller is the low cavitation design. Self-lubricating bearings or forced lubricating bearings could be applied for different power, speed, and another service requirement.

  • Capacity 5~900m3/h
  • Head ~4000m
  • Design Pressure ~45.0Mpa
  • Temperature -80~+450℃
  • Speed 6000r/min
  • Power ~12000KW

The DCS-K series is a double-casing, horizontal-split, horizontal, multistage centrifugal pump designed for extreme conditions such as high temperature and high pressure. It is centerline-mounted, features a heavy-duty design with good thermal stability, and can properly satisfy the nozzle load requirements specified by API610. The double-casing structure ensures high safety and reliability. The inner casing is an integral pull-out design, allowing for easy installation and simple maintenance. The impellers are arranged back-to-back without traditional balancing devices, ensuring stable and reliable operation. The first-stage impeller is designed with low cavitation. The pump can be fitted with self-lubricating bearings or forced lubricating bearings to meet different power, speed, and service requirements.

  • Capacity 10~2000m3/h
  • Head ~4000m
  • Design Pressure ~45.0Mpa
  • Temperature -80~+450℃
  • Speed 6000r/min
  • Power ~25000KW

The DCS-G series is a horizontal, double-casing, radial-split, multistage pump with series arrangement impellers. The pump is centerline-mounted, features a heavy-duty design with good thermal stability and can properly satisfy the nozzle load requirements specified by API610. The double-casing structure ensures high safety and reliability. The inner casing is an integral pull-out design, allowing for easy installation and simple maintenance. The pump uses a single or double-balancing drum structure to balance the axial force, ensuring stable and reliable operation. The first-stage impeller is designed with low cavitation. The pump can be fitted with self-lubricating bearings or forced lubricating bearings to meet different power, speed and service requirements.

  • Capacity 5~1350m3/h
  • Head ~3800m
  • Design Pressure ~42.0Mpa
  • Temperature -80~+450℃
  • Speed ~6000r/min
  • Power ~20000KW

The LYA-I series is a vertical, single-stage, single-suction, radial-split, long-shaft submerged pump with a volute casing. It features an independent side discharge pipe, resulting in less hydraulic loss and high efficiency. The balancing chamber and pipe help to decrease pressure and axial force, reducing the possibility of particles entering the sliding bearing, which helps to avoid wear on the plain bearing and prolongs the service life of the pump. The axial force can be balanced by the back blade of the impeller, as well as a pair of angular contact ball bearings for residual axial force balancing. According to the different pump lengths, both integral shaft and spindle shaft structures are available for the pump shaft. To meet different client requests, various types of seals, such as gland seals, packing, screw seals, and mechanical seals, can be fitted. In case of special requirements or working conditions, the ZL bearing group can be fitted, which is light oil lubricated.

  • Capacity 3~1100m3/h
  • Head ~135m
  • Design Pressure ~2.5Mpa
  • Temperature -60~+200℃
  • Speed ~2980r/min、1475r/min
  • Power ~132KW

The LDB series is a vertical, double-casing, radial-split, radial diffuser or bowl type, multistage centrifugal pump. It features a welding structure for the inlet and outlet section and barrel bag void defects. The first-stage impeller and second-stage impeller have different designs, with the first-stage impeller being based on high cavitation resistance and the second-stage impeller designed for pump efficiency. The impellers can be designed with a diffuser to reduce insertion depth under cavitation-demanding conditions. The pump uses either a balancing drum (LDB-B) or disk (LDB-A) design to balance the axial force. The flexible shaft is multi-point supported and the distance between supporting points conforms to API610 standard. The pump is equipped with ZL series bearing group, which is grease lubricated and has residual axial force balanced by a pair of angular contact ball bearings.

  • Capacity 15~4400m3/h
  • Head ~400m
  • Design Pressure ~11.0Mpa
  • Temperature -80~+250℃
  • Speed ~2980r/min、1475r/min
  • Power ~1500KW

The LDB series is a vertical, double-casing, radial-split, radial diffuser or bowl type, multistage centrifugal pump. It features a welding structure for the inlet and outlet section and barrel bag void defects. The first-stage impeller and second-stage impeller have different designs, with the first-stage impeller being based on high cavitation resistance and the second-stage impeller designed for pump efficiency. The impellers can be designed with a diffuser to reduce insertion depth under cavitation-demanding conditions. The pump uses either a balancing drum (LDB-B) or disk (LDB-A) design to balance the axial force. The flexible shaft is multi-point supported and the distance between supporting points conforms to API610 standard. The pump is equipped with ZL series bearing group, which is grease lubricated and has residual axial force balanced by a pair of angular contact ball bearings.

  • Capacity 4~700m3/h
  • Head ~1100m
  • Design Pressure ~11.0Mpa
  • Temperature -120~+250℃
  • Speed ~2980r/min、1475r/min
  • Power ~1500KW

The High-pressure submersible pump is a vertical, multistage, radial-split, diffuser structure centrifugal pump installed outside the storage tank. The pump head is installed inside the suction cylinder, which is installed as a pit-type. The flow passage component and motor have a coaxial design, with the pump being submerged in the medium. The pump uses a minor radius balance disk and drum combination design to balance the axial force. It has a 3-point rolling bearing support with auxiliary support provided between stages to improve stability. Without dynamic sealing, the only leakage point is the leakage of the medium in the pump well along the cable, resulting in zero leakage, cooling by the pumping medium, explosion-proof requirements and reliability. The pump is equipped with a vibration, liquid level, temperature, and pressure monitoring system to ensure the safety of the pump operation.

  • Capacity 600m3/h
  • Head ~3000m
  • Design Pressure ~15Mpa
  • Temperature ~-196℃
  • Speed 3000r/min
  • Power ~2800KW

The In-tank submersible pump is a 3-point rolling bearing support, vertical single-stage/multistage, closed-type impeller, radial/axial split diffuser centrifugal pump. The pump is installed inside the pump well and the connection and isolation between the pump well and the storage tank are achieved through the opening and closing of the pump control bottom valve, which is installed at the pump inlet. The flow passage component and motor have a coaxial design, with the pump being submerged in the medium. The pump uses a minor radius balance disk and drum combination design to balance the axial force. The only leakage point is the leakage of the medium in the pump well along the cable, resulting in zero leakage without dynamic sealing. Proper cooling by the pumping medium, no explosion-proof requirements, high safety and reliability.

  • Capacity 2500m3/h
  • Head ~810m
  • Design Pressure ~7.5Mpa
  • Temperature ~-196℃
  • Speed 1480r/min~3000r/min
  • Power 15KW~1000KW
